OV02640-V38H OmniVision 2MP 2百万像素手机摄像头CMOS SENSOR图像传感器
2021-05-27 02:29:26

OV2640 Color CMOS UXGA (2.0 MegaPixel) CAMERA CHIP TM Sensor with OmniPixel2 TM Technology


General Description
The OV2640 CAMERACHIP TM image sensor is a low voltage CMOS device that provides the full functionality of a single-chip UXGA (1632x1232) camera and image processor in a small footprint package. The OV2640 provides full-frame, sub-sampled, scaled or windowed 8-bit/10-bit images in a wide range of formats, controlled through the Serial Camera Control Bus (SCCB) interface.
This product has an image array capable of operating at up to 15 frames per second (fps) in UXGA resolution with complete user control over image quality, formatting and output data transfer. All required image processing functions. including exposure control, gamma, white balance, color saturation, hue control, white pixel canceling, noise canceling, and more, are also programmable through the SCCB interface. The OV2640 also includes a compression engine for increased processing power. In addition, OmniVision CAMERACHIP sensors use proprietary sensor technology to improve image quality by reducing or eliminating common lighting/electrical sources of image contamination, such as fixed pattern noise, smearing, etc., to produce a clean, fully stable color image.

Note: The OV2640 uses a lead-free package.

Features
※  High sensitivity for low-light operation
※ Low operating voltage for embedded portable apps
※ Standard SCCB interface
※ Output support for Raw RGB, RGB (RGB565/555),GRB422. YUV (422/420) and YCbCr (4:2:2) formats
※ Supports image sizes: UXGA, SXGA, SVGA, and any size scaling down from SXGA to 40x30
※ VarioPixe method for sub-sampling
※ Automatic image control functions including Automatic Exposure Control (AEC), Automatic Gain Control (AGC), Automatic White Balance (AWB), Automatic Band Filter (ABF). and Automatic Black-Level Calibration (ABLC)
※ Image quality controls including color saturation, gamma, sharpness (edge enhancement), lens correction, white pixel canceling, noise canceling, and 50/60 Hz luminance detection
※ Line optical black level output capability
※ Video or snapshot operationZooming, panning, and windowing functions Internal/external frame synchronization
※ Variable frame rate control
※ Supports LED and flash strobe mode
※ Supports scaling
※ Supports compression
※ Embedded microcontroller

Ordering Information
Product:OV02640-VL9A (Color, lead-free),Package38-pin CSP2

Functional Description
Figure 2, shows the functional block diagram of the OV2640 image sensor. The OV2640 includes:
※ Image Sensor Array (1632 x 1232 total image array)
※ Analog Signal Processor10-Bit A/D Converters
※ Digital Signal Processor (DSP)
※ Output Formatter
※ Compression Engine
※ Microcontrolle
※ SCCB Interface
※ Digital Video Port
