ICX663AKA 1/3 960H Super HAD CCD II Sensor，SONY索尼1/3-inch WDR宽动态CCD analog output image sensor PAL逐行扫描模拟输出960TVL CCD安防监控摄像机图像传感器
2022-08-15 18:14:34
点击购买
SONY ICX663AKA，SONY索尼1/3-inch CCD, WDR宽动态CCD, analog output CCD , image sensor, PAL逐行扫描模拟输出，960TVL CCD图像传感器，安防监控摄像机CCD传感器 ,1/3" 960H Super HAD CCD II Sensor
Main control chip DSP: CXD4129GG,
AFE: CXD5148GG
Signal System Signal System
PAL: ICX663AK, Pixels (H) x 1028 (V) 596
NTSC format :ICX662AK, pixel,(H)1028x(V)508
Horizontal Resolution:700TVL
Minimum lllumination:0.001Lux
Real WDR / 2D/3D DNR/SENS UP/Motion Detection/HLT
Scan: Scan line by line
Wide dynamic range: 128X, 56dB
Synchronization system: internal synchronization INT
Horizontal frequency ICX663AK: 15.625kHz
Horizontal frequency ICX662AK: 15.734kHz
Vertical frequency ICX663AK: 50.00Hz, ICX663AK: 59.94Hz
Definition: 720TVL, 720TVL
Video output: Composite image signal output, 1.0VP-P at 75OHM
SNR: 52dB(min)/60dB(Max)(automatic gain off)
Gamma correction: 0.45
Automatic gain: +56dB Max
Aperture control: Electronic shutter /DC drive
Electronic shutter: 1/60(1/50)~1/100000 SEC
产品型号:ICX663AKA
1/3 SONY EFFIO-P 700TVL CCD
主控芯片DSP：CXD4129GG，
AFE：CXD5148GG
信号制式Signal System
PAL制式:ICX663AK,Pixels(H)1028x(V)596
NTSC制式:ICX662AK,像素 ,(H)1028x(V)508
分辨率 Horizontal Resolution:700TVL
最低照度Minimum lllumination:0.001Lux
功能：Real WDR / 2D/3D DNR / SENS UP / Motion Detection / HLT
扫描：逐行扫描
宽动态范围：128X， 56dB
同步系统：内同步INT
水平频率ICX663AK：15.625kHz
水平频率ICX662AK：15.734kHz
垂直频率ICX663AK：50.00Hz，ICX663AK：59.94Hz
清晰度：720TVL，720TVL
视频输出：复合式影像信号输出,1.0Vp-p at 75ohm
信噪比：52dB(最小)/60dB(最大)(自动增益关闭)
伽玛修正：0.45
自动增益：+56dB最大
光圈控制：电子快门/DC驱动
电子快门：1/60(1/50)~1/100000 sec
有关ICX663AK的价格，datasheet download免费下载，简介，PDF文档下载，电路图，原理图，框架图，文档下载，原装现货，现货库存，芯片，图片，规格书下载，代理商，技术支持，产品介绍，参数，方案，分销，经销，官网，生产厂家，批量采购，模组，模块，特价，库存，哪里买，性价比，用途，封装厂，晶圆，代工，可咨询本公司
点击或者复制上面链接到浏览器打开，ICX663AK datasheet PDF file可免费下载，Click or copy the link to free download the datasheet PDF file.
满2件全国包邮，如果你有货，可以卖给我，当我求购ICX663AK，你需要购买ICX663AK，可以找我买。
Freight is free when you buy 2 pieces in China, if you have ICX663AK inventory, you can sell to me, if you need buy ICX663AK, you can ask me to buy.
