A12A75 Advanced HD Automotive Camera SoC

The A12A75 SoC family enables single-channel Quad HD (4MP, 1440p) at 30fps, Full 1080p HD at up to 60 fps, and dual-channel Quad HD, providing support for video recording through the front windshield as well as through the rear window or inside the vehicle.
The A12A75 combination of advanced image processing, High Dynamic Range (HDR), 3D noise filtering, smart auto-exposure, and full-resolution oversampling provides superior image quality, allowing the capture of license plates and other key details, even in low light conditions. The increased resolution allows a wider field of view to be captured, while still maintaining a high level of detail throughout the image.
The A12A75 SoC includes a high-speed 792-MHz ARM? Cortex?-A9 CPU with Neon DSP extensions to support advanced analytics algorithms including Lane Departure and Forward Collision Warning Systems.
A12A enables WiFi connectivity for reviewing the captured video clips on iOS and Android devices as well as an interface to 4G/LTE modems for remote viewing or cloud storage of the video. The SDK leverages Ambarella’s multi-stream encoding capability for Full HD video recording while simultaneously sending a second stream to the smartphone.

Key Features
Unparalleled Performance
° Full HD @ 60fps or Quad HD 4MP @ 30fps
° Two-channel Quad HD @ 30fps
° Electronic Image Stabilization (EIS)
Superior Image Quality
° Advanced Night Vision for Low Light Conditions
° Full-Resolution Oversampling
° Wide Dynamic Range (WDR)
° High Dynamic Range (HDR)
° Automotive Smart Auto Exposure
Advanced Features
° Advanced Driver Assistance System (ADAS)
° WiFi and 4G/LTE Connectivity Support

General Specifications
Image Sensor Interface
° 500 MPixels/s sensor data input
° LVDS, sub-LVDS, SLVS/MLVS
° LVCMOS, Parallel, MIPI, HiSPi?

High Performance Automotive Video Engine
° Quad HD 4MP @ 30fps, Full 1080p HD @ 60fps
° Simultaneous encode of two high-resolution Quad HD 4MP @ 30fps streams for front and rear cameras
° Advanced Night Vision with super-resolution oversampling, 3D noise filters and dynamic tone mapping
° Real-time geometric distortion correction (de-warp) filter
° Advanced automotive dynamic range engine with local exposure, highlight and tone adjustment
° Automotive smart auto exposure (AE) with scene detection, object detection and dynamic AE
° Continuous looping, motion detection and event-based/emergency video

Powerful CPU For Advanced Driver Assistance
° ARM? Cortex?-A9 @ up to 792 MHz
° 32 KB/32 KB I/D and 128 KB L2 Cache
° AES/3DES/SHA-1/MD5 Cryptography Engine
° Ambarella Image and Video DSPs
° Includes Lane Departure Warning System (LDWS)
° Forward Collision Warning System (FCWS)
° Forward Car Movement Detection (FCMD)
° Low Light Warning (LLW)

File Formats
° Audio: AAC (Two-channel LC, HEAAC, HEAAC v2), ADPCM / LPCM / PCM
° Photo File: JPG

Advanced Video and Display Processing
° BP/MP/HP H.264 Level 5.0 and MJPEG encode
° Crop, mirror, flip, scale functions and LCD rotation
° Alpha-blending OSD; text, overlays
° Multiple video output ports

Memory Interfaces
° DDR3/DDR3L up to 600 MHz
° 16-bit/32-bit data bus
° Three SD controllers with SDXC SD? Card
° NAND flash, SLC with ECC
° Boot from SPI-NOR, SPI-EEPROM, NAND flash, USB or eMMC

Peripheral Interfaces
° Two USB 2.0 ports with Device and Device/Host w/PHY
° Multiple SSI/SPI, I2C/IDC, and UART
° Multiple PWM, Stepper, and ADC channels
° Numerous GPIO ports, PWM, Steppers, IR, ADC
° Watchdog Timer, multiple general-purpose timers, JTAG, I2S

Physical
° 28-nm low-power CMOS
° Two LFBGA packages available:
    ° 404 balls, 15x15 mm, 0.65 mm pitch(our instock)
    ° 256 balls, 11x11 mm, 0.65 mm pitch  (no stock)
° Operating temperature: -20℃ to +85℃ or -40℃ to +105℃

A12A75 Advanced HD Automotive Camera Development Platform
The A12A75 Automotive Camera Development Platform contains the necessary tools, software, hardware and documentation to develop a small form factor, automotive camera.

Evaluation Kit (EVK)
° A12 main board with connectors for sensor/lens board, peripherals
° Sensor board: Omnivision, Sony, and others
° Data sheet, BOM, schematics, and layout
° Reference application with C source code

Software Development Kit (SDK)
° Dual OS ThreadX/Linux with patches, drivers, tools, and application source code
° Royalty-free libraries for ISP, 3A, dewarp, and codecs
° Image tuning and manufacturing calibration tools
° Detailed documentation with programmer’s guide, application notes
安霸Ambarella A12A75报价,参数,功能,性价比,供应商,代理商,分销商,厂家,,安霸官网,分销商,现货,规格书,高清图片,方案商,安霸代理商,官网,深圳办事处,中国代表处,Ambarella行车记录芯片,仪航拍芯片,运动相机主控,运动相机芯片,h.264编码器,2560x1440p@60fps处理器,H.264视频编码处理器,视频SoC,可穿戴视频IC,安霸无人机相机IC,安霸汽车记录仪,低功耗SoC,视频解压缩芯片,高清视频处理器,2k视频处理器

A12A75高级高清汽车摄像头SoC

A12A75 SoC系列支持30帧/秒的单通道四倍高清(4MP, 1440p), 60帧/秒的全1080p高清,以及双通道四倍高清,支持通过前挡风玻璃、后窗或车内的视频录制。
A12A75结合了先进的图像处理、高动态范围(HDR)、3D噪声滤波、智能自动曝光和全分辨率过采样功能,提供了卓越的图像质量,即使在弱光条件下也能捕获车牌和其他关键细节。 增加的分辨率允许更广阔的视野被捕获,同时仍然保持一个高水平的细节在整个图像
A12A75 SoC包括一个高速792 mhz ARM Cortex -A9 CPU,霓虹灯DSP扩展,支持先进的分析算法,包括车道偏离和前方碰撞预警系统。
A12A75支持WiFi连接,可在iOS和Android设备上查看拍摄的视频片段,并提供4G/LTE调制解调器的接口,用于远程观看或云存储视频。 该SDK利用了Ambarella的多流编码能力,用于全高清视频录制,同时向智能手机发送第二个流。

关键特性
无与伦比的性能
※ 全高清@ 60帧或四高清4MP @ 30帧
※ 双通道四帧高清,30帧
※ 电子稳像

卓越的图像质量
※ 低光条件下的高级夜视
※ 全分辨率采样过密
※ 宽动态范围(WDR)
※ 高动态范围(HDR)
※ 汽车智能汽车曝光

先进的功能
※ 高级驾驶辅助系统(ADAS)
※ WiFi和4G/LTE连接支持

通用规范
图像传感器接口
※ 500 MPixels/s传感器数据输入
※ LVDS, sub LVDS, SLVS/MLVS
※ LVCMOS, Parallel, MIPI, HiSPi?

高性能汽车视频引擎
※ 四通道高清4MP @ 30fps,全高清1080p @ 60fps
※ 前置和后置摄像头同时编码两个高分辨率四通道高清4MP @ 30fps流
※ 高级夜视超分辨率  过采样,3D噪声滤波器和动态  色调映射
※ 实时几何畸变校正(反翘曲)滤波器
※ 高级汽车动态范围引擎,局部曝光,高光和色调调整
※ 汽车智能汽车曝光(AE),具有场景检测、物体检测和动态AE
※ 连续循环,运动检测和
※ 基于事件/紧急视频

强大的CPU高级驱动辅助
※ ARM® Cortex™-A9 @ up to 792 MHz
※ 32kb / 32kb I/D和128kb L2 Cache
※ AES/3DES/SHA-1/MD5加密引擎
※ Ambarella图像和视频dsp
※ 包括车道偏离警告系统(LDWS)
※ 航向碰撞预警系统(FCWS)
※ 前进°汽车运动检测(FCMD)
※ 弱光警告(LLW)

文件格式
※ 音频:AAC(双通道LC, HEAAC, HEAAC v2), ADPCM / LPCM / PCM
※ 图片文件:JPG

高级视频和显示处理
※ BP/MP/HP H.264 5.0级和MJPEG编码
※ BP/MP/HP H.264 5.0级和MJPEG编码
※ Alpha-blending OSD; 文本,覆盖
※ 多个视频输出接口

内存接口
※ DDR3/DDR3L高达600 MHz
※ 16位/32位数据总线
※ 三SD控制器与SDXC SD? 卡
※ NAND闪光,SLC带ECC
※ Boot从SPI-NOR, SPI-EEPROM, NAND闪存,USB或eMMC

外围接口
※ 两个USB 2.0接口,带设备和带PHY的设备/主机
※ 多种SSI/SPI、I2C/IDC、UART
※ 多个PWM,步进,ADC通道
※ 众多的GPIO端口,PWM,步进,IR, ADC
※ 看门狗定时器,多用途定时器,JTAG, I2S

物理
※ 28纳米低功耗CMOS
※ 两个LFBGA包可用:
※ 封装:404锡球,15x15毫米,0.65毫米间距(本公司货仅有此封装)
               256 balls, 11x11 mm,    0.65 mm pitch (缺货)
※ 工作温度:-20℃ + 85℃或-40℃ + 105℃
※ A12A75高级高清汽车摄像头开发平台
※ A12A75汽车摄像头开发平台包含开发小型汽车摄像头所需的工具、软件、硬件和文档。

评估工具(EVK)
※ A12主板,带有传感器/镜头板和外围设备的连接器
※ 传感器板:Omnivision、Sony等
※ 数据表,BOM,示意图和布局
※ 参考应用程序与C源代码

软件开发工具包(SDK)
※ 双操作系统ThreadX/Linux,带有补丁、驱动程序、工具和应用程序源代码
※ ISP, 3A, dewarp和codecs免版税库
※ 图像校正和制造校准工具
※ 详细的文档与程序员指南,应用说明

Ambarella Inc是低功耗、高清(HD)和超高清视频压缩、图像处理和计算机视觉解决方案的领先开发商。该公司的产品应用于各种IP安防监控、运动相机、可穿戴、无人机和汽车摄像机的视频处理。Ambarella levera的解决方案……
1.视频处理器SoC瞄准口袋大小的混合摄像机。
2.低功耗相机SoC提供60fps H.264

Ambarella Inc is a leading developer of low-power, high-definition (HD) and Ultra HD video compression, image processing, and computer vision solutions. The company’s products are used in a variety of IPC security, sports(Action), wearable, drone, and automotive video cameras. Ambarella’s solutions levera...

1. Video Processor SoC targets pocket-sized hybrid cameras.

2. Low-power camera SoC provides 60 fps H.264

Ambarella表示,A12A芯片支持前挡风玻璃、后窗和车内的视频录制,提供30帧/秒的单通道四帧高清(4MP, 1440p),最高60帧/秒的全1080p高清,以及双通道四帧高清性能。

According to Ambarella, the A12A chip provides support for video recording through the front windshield, rear window, and inside the vehicle cabin, delivering single-channel Quad HD (4MP, 1440p) at 30fps, Full 1080p HD at up to 60 fps, and dual-channel Quad HD performance.

USB 2.0接口:2 x
核心:1
核心信息:cortex - a9
视频编解码器支持:h
图像数量:1
最大视频分辨率:4mp

Interfaces:2x USB 2.0
Cores:1
Core Information: Cortex-A9
Video Codec Support:h.264
Number of Imagers :1
Max Video Resolution:4 MP
